MICCAI 2026 Young Scientist Award

TopoOR: A Unified Topological
Scene Representationfor the Operating Room

Tony Danjun Wang^1,2

Ka Young Kim⁴

Tolga Birdal³

Nassir Navab^1,2

Lennart Bastian^1,2,3

¹ Technical University of Munich² Munich Center for Machine Learning³ Imperial College London⁴ Kyung Hee University

arXiv MICCAI 2026 Code

The Surgical Operating Room as Multi-Modal Topological Complex. Illustration shows estimated human poses and objects (of one time step) that form the physical entities of the TopoOR representation.

Modeling Complex Multi-Modal Surgical Interactions

Surgical actions depend on coordination among people, instruments, and equipment. We introduce TopoOR, the first application of topological deep learning to multimodal scene networks, to explicitly model these interactions. For robot-assisted surgery, for instance, this means modeling the surgeon, robot, saw, and patient as one interacting group.

TopoOR organizes these groups and their constituent entities into a combinatorial complex, combining human poses and object locations with sensor data from cameras, medical devices (e.g., robots), and microphones. Higher-order attention exchanges information between individual entities and the groups they participate in, with temporal links connecting the scene across frames.

How to Represent Relations

Graph

Each edge connects two nodes.

Hover or tap a node.

Edges A–B and B–C do not imply an A–C edge.

For a rigorous treatment of higher-order networks, we refer to Topological Deep Learning.

Method Overview

TopoOR pipeline: human poses, object locations, and multimodal evidence are organized into a combinatorial complex. Higher-order attention exchanges information among entities, pairwise relations, and interaction groups. The final panel illustrates exempllary downstream tasks using this representation. — TopoOR Representation. A combinatorial complex unifies individual multi-modal entities, pairwise relations, and interactions among multiple participants under a single representation. Higher-order attention exchanges multimodal information across this structure.

A Proposed Representation

Rank 0: Human joints and objects (3D); evidence nodes for robot logs, monitor images, and audio.
Rank 1: Skeleton edges, proximity-based edges, and predefined links such as Technician–Robot.
Rank 2: Person cells aggregate each skeleton; functional cells group participants in a surgical interaction.

Higher-Order Attention

Each cell attends to its incident lower- and higher-rank cells. Entity features propagate toward group cells, and group features propagate back to their constituents. A learned bias, indexed by the source and target ranks, adjusts the attention weights.

Image features are sampled at the projected 3D node locations and fused across camera views. Bidirectional temporal edges connect corresponding entities across an eight-frame window.

Results on MM-OR

We evaluate next-action anticipation, robot-phase prediction, sterility-breach detection, and scene-graph relation prediction using the standard train and test splits of the MM-OR dataset. All scores are macro-F1 on a 0–100 scale; higher is better.

Table 1 Downstream Task Performance
Method	Sterility Breach^†	Next Action	Robot Phase
LLM-Based
MM2SG (Özsoy et al.)	55.00	35.40	56.90
Latent & Relational Models
Vanilla Transformer (Vaswani et al.)	76.83	34.80	65.29
SurgLatentGraph (Murali et al.)	76.83	37.46	64.61
TopoOR (ours)	76.83	41.10	73.53

Best results in bold, including ties. † For the Vanilla Transformer, SurgLatentGraph, and TopoOR, sterility is evaluated with shared geometric rules on the estimated 3D scene. This evaluation is independent of the learned action and phase predictions, yielding the same sterility F1 for all three.

TopoOR improves next-action F1 by 3.64 points over SurgLatentGraph (Murali et al.) and robot-phase F1 by 8.24 points over the Vanilla Transformer (Vaswani et al.). Sterility performance is, naturally, tied across all three geometric methods.

Robot-phase timelines compared with ground truth, estimated 3D operating-room entities, and diagrams showing unstructured, pairwise, and higher-order scene representations. — Qualitative Results. Robot-phase predictions compared with ground truth (left), estimated 3D scene entities (center), and schematic representations of the Vanilla Transformer, SurgLatentGraph, and TopoOR (right).

Scene-Graph Relation Prediction

A relation head trained on the full complex predicts conventional scene-graph labels, reaching 61.30 F1 versus 52.90 for MM2SG (Özsoy et al.). A simple decision tree restricted to rank-0 spatial entities reaches 43.72.

Table 2 Scene-Graph Relation Prediction
Method	F1
MM2SG (Özsoy et al.)	52.90
Ours (Decision Tree)	43.72
Ours (Learned Head)	61.30

Incremental Modality Ablation

Adding RGB features to objects and skeletons raises robot-phase F1 from 20.25 to 60.71. Adding robot logs, audio, and temporal links then raises it to 73.53. Each row adds a modality to the preceding configuration.

Table 3 Incremental Modality Ablation
Object Nodes	Human Skeleton	RGB Images	Robot Logs	Audio	Temporal Links	Next Action	Robot Phase
✓	—	—	—	—	—	25.82	21.08
✓	✓	—	—	—	—	26.26	20.25
✓	✓	✓	—	—	—	36.35	60.71
✓	✓	✓	✓	—	—	38.26	67.06
✓	✓	✓	✓	✓	—	40.57	69.63
✓	✓	✓	✓	✓	✓	41.10	73.53

Temporal context spans eight frames.

Beyond MM-OR (Limitations)

Our experiments use MM-OR. Further evaluation across surgical tasks, procedures and hospitals would help establish how well the representation transfers to new teams, equipment, and workflows.

Citation

@inproceedings{wang2026topoor,
  author    = {Wang, Tony Danjun and Kim, Ka Young and Birdal, Tolga
               and Navab, Nassir and Bastian, Lennart},
  title     = {{TopoOR}: A Unified Topological Scene Representation
               for the Operating Room},
  booktitle = {Medical Image Computing and Computer Assisted Intervention -- MICCAI 2026},
  year      = {2026},
  publisher = {Springer Nature Switzerland},
  series    = {Lecture Notes in Computer Science},
  volume    = {16892},
  month     = sep,
  url       = {https://papers.miccai.org/miccai-2026/1068-Paper2412.html}
}
